| No. | Name | Remarks |
| 1 | Frame size | L13500XW3000XH1780 size can make according to customer's requirements |
| 2 | Tare weight | 15 ton+5%expension |
| 3 | Payload | 60 ton |
| 4 | Floor plate | 5mm checker plate |
| 5 | Painting | Wax whole trailer, anti-corrison primer,polyurethane paint,color as per customer's requirement. |
| 6 | Ramp | Double spring reinforced type. |
| 7 | Axles | 13 ton axles |
| 8 | Wheel rim | 8.25-22.5 |
| 9 | Tyre | 11.00R-22.5 |
| 10 | Leaf spring | 90width*10 pieces*13thickness |
| 11 | Kingpin | 3.5"(90#) |
| 12 | Landing legs | Two speed landing gear |
| 13 | Suspension | Jupiter machanical type |
| 14 | Air tank | jupiter |
| 15 | Brake chamber | 2 pcs T3030,4 pcs T30 |
| 16 | Air connector | one units reliable local brand stander air connector |
| 17 | Relay valve | WABCO valve |
| 18 | 7-pin socket | one unit of 24V 7-pin socket |
| 19 | Lamb | tail lamb with turn signal,brake light…including a whole set of stander lamb |
| 20 | Cable | one set of stander cable |
