TEM

JG9320GYY

JG9400GYY

JG9401GYY

overall outside dimension

(mm)

length

13000

13000

12500

width

2500

2500

2500

Height (unload)

3800

3550

3700

Outside dimension of tank body(mm)

length

12730

12670

12150

Capacity(L)

36100

43560

45420

GVW(kg)

31900,31500

39600

39660

vehicle total weight(kg)

8900,8500

11160

10660

rated payload(kg)

23000

28500

29000

Wheel base(mm)

8170+1310

6960+1310+1310

6660+1310+1310

Tread

(mm)

Tread at front




Tread at rear

1830

1840

1840

Front/Rear suspension(mm)

/2300,2500

-/1440

/2000

Approach/Departure angle°

/19,17

-/22

/18

Rated payload of Vehicle saddle

14100,14000

16000

15670

Tyres

11.00-20

11.00-20

12.00-20

We can provide you all kinds of tank semitrailer, with different capacity and materials. You just tell us your request, then we will provide you the quotation.
