Products

Traction type

6X4

Driving type

LHD/RHD

Dimension(Lx W xH)unloaded

10576×2500×3430

Wheel base(mm)

5050+1450

Max speedkm/h

90

Curb weightkg

12000

Loading Weightkg

25,000

Engine

Steyr technology, made in China

Model:WD615.380

water-cooledfour strokes6 cylinders in lineturbocharged, directly injection With the exhaust valve brake, EGR (gas exhausted recycling), deisel engine

DisplacementL

9.726/Diesel

Bore X stroke(mm)

126/130

Max powerkw/rpm

247/2200 (380hp)

Max torqueNm/rpm

1500/1300-1600

Emission

EURO II

Fuel tankerL

400L steel fuel tanker

Clutch

Model

430 Diaphragm type

Gearbox

Model

9JS150 (Fuller)

mechanism,

9gears, 1reverse gear

Brake system

Service brake

Brake gap can be adjusted automatically, double circulation air brake system

Assistant brake

Engine exhaust brake

Park brake

Potential springs pressing on middle and rear wheels

Steering system

Model

ZF8098

Frame

Fish belly, shape, variable width, variable sections, side beam structure

Front axle (Mercedes Benz  Technology)

7.5T Double-shoe pneumatic brake, non-driving steering axle



Middle and Rear axle (Mercedes Benz Technology)

13T Double-shoe pneumatic brake, casting, double reduction driving axles with inter-wheel & inter-axles differential locks



Tyre

12.00R20 Radial tyre Number of tyre:10+1 spare

Electrical system

Battery

2X12V/135Ah

Generator

28V-35A

Starter

5.4Kw/24V

Cab

Mercedes-Benz technology NG80B long Cabin, single sleeper with air-conditioner

Full steel skeleton structure, covered with double layer steel plate;

Can be tipped forwardly;

                       Water tank

Tank capacity

10,000 liters ~30,000 liters

Thickness of the tanker body

the thickness of the shell is 5mm approx;

Dish ends

the thickness of the shell is 6mm approx;
