NORTH BENZ 8 X4 Dump Truck | |
Model | ND3319D35J |
Driving type | LHD (Right Hand Drive is optional） |
Driver's cab | Long cabin, with one sleeper |
Engine | Maker: WEICHAI |
Diesel 4 stroke direct injection diesel engine, 6 cylinder in-line with water cooling, turbo-charging & intercooling | |
Engine model: WD12.420 EURO II/EUROIII emission standard | |
Maximum output: 420@2200rpm | |
Number of cylinder:6 | |
Displacement:12 L | |
Clutch | 430mm, hydraulically operating with air assistance |
Transmission | FULLER Brand transmission. |
Front Axle | Benz front axle 6.5 tons |
Rear Axle | Benz TYPE double reduction drive axle |
Steering | TAS85 |
Option: ZF8098, hydraulic steering with power assistance | |
Wheel & Types | Tyres: 12.00R20 |
Optional: 12R22.5 | |
Radial tire and tubeless tire is optional | |
Electrics | Operating voltage: 24V, negative grounded |
Dimensions in mm | Wheel base: 1500+3550+1450 |
Overall size: 9300x2300x3484 | |
Weight in kg | Kerb weight 14765 |
Permissible trailing capacity 50000 | |
Performance | Maximum driving speed(km/h) 85 |
Body mm | 8000x2300x1500 Floor 8 side&back6, hydraulic front tipping type |
The manufacture reserves the right of technical alteration/change for better improvement prior notice | |
